Player One Uranus-C Colour Camera
Uncooled colour camera with the Sony IMX585 1/1.2″ sensor. 8.3 MP, 2.9 µm pixels, 12-bit.
£295.00
Free tracked UK delivery
Usually in stock
- Pay by card or PayPal
- UK company in Shrewsbury
- Call 01743 224 180 or WhatsApp
- Delivery
- Free tracked UK delivery. Outside the UK, the cost is shown in your basket. Delivery
- Warranty
- 2-year manufacturer warranty, handled by us in the UK.
- Returns
- 14 days to return unused items. Returns policy
Same IMX585 sensor, other versionsSee all 8 IMX585 cameras
- Player One Uranus-C Pro Colour Cooled CameraPlayer One · colour · cooled
- Player One Uranus-M Mono CameraPlayer One · mono · uncooled
- Player One Uranus-M Pro Mono Cooled CameraPlayer One · mono · cooled
- Player One Xena 585M Mono CameraPlayer One · mono · uncooled
Overview
The Player One Uranus-C is an uncooled colour astronomy camera built around Sony’s IMX585 sensor. It is made for the planets, the Moon and live stacking of deep-sky objects.
The sensor is larger than most planetary cameras. On a Celestron C8 at f/10 it covers about 19 × 11 arcminutes, which helps when a planet drifts or when you image the Moon. The 2.9 µm pixels are best matched at around f/14.
Each pixel holds up to 47,000 electrons, much more than older sensors of this size, and read noise drops to 0.7 e⁻ at high gain. The camera runs at 47 frames per second at full resolution, and dark frames show no amp glow.
The window is AR-coated, not IR-cut, so add a UV/IR-cut filter for natural colour. A 256 MB buffer stops dropped frames on a slower laptop or USB 2.0 port.
The body has a passive heatsink. Our Player One Active Cooling System fits if you want to keep it close to air temperature on long sessions.
Specifications
| Sensor | Sony IMX585, colour |
|---|---|
| Sensor format | 1/1.2″ |
| Sensor size | 11.2 × 6.3 mm |
| Diagonal | 12.85 mm |
| Image size | 3856 × 2180 px |
| Sensor megapixels | 8.3 MP |
| Pixel size | 2.9 µm |
| Shutter | Rolling |
| ADC | 12 bit |
| Full well | 47 ke⁻ |
| Read noise, low to high gain | 7.2–0.7 e⁻ |
| Peak QE | 91% |
| Cooling | None: passive heatsink (optional active cooling kit) |
| Max frame rate | 47 fps (10-bit) |
| Image buffer | 256 MB |
| Back focus | 12.5 mm |
| Connection | USB 3.0 |
| Adapters | M42×0.75, 1.25″ |
| Weight | 160 g |
| Body diameter | 66 mm |
Image scale and field of view
What this camera covers at common telescope focal lengths, from its 2.9 µm pixels and 11.2 × 6.3 mm sensor. How to read these figures
| Focal length | Image scale | Field of view |
|---|---|---|
| 250 mm | 2.4″ per pixel | 2.6° × 1.4° |
| 400 mm | 1.5″ per pixel | 1.6° × 54′ |
| 600 mm | 1.00″ per pixel | 1.1° × 36′ |
| 1,000 mm | 0.60″ per pixel | 39′ × 22′ |
| 2,000 mm | 0.30″ per pixel | 19′ × 11′ |
Specifications from Player One. Check with us if a figure matters for your setup.
In the box
- Camera with 1.25″ T-mount
- USB 3.0 cable
- ST4 guide cable
- 1.25″ dust cover
- Air blower
- M2 hex key
