ToupTek ATR432C Colour Cooled Camera
Cooled colour camera with the Sony IMX432 1.1″ sensor. 1.8 MP, 9 µm pixels, global shutter, 12-bit.
£1,090.00
No VAT added. The price you see is the price you pay.
Usually in stock
If it isn’t on the shelf when you order, we’ll email you within one working day with a confirmed delivery date, usually within 10 days.
Same IMX432 sensor, other versionsSee all 3
- Player One Apollo-M MAX Mono CameraPlayer One · mono · uncooled
- ToupTek ATR432M Mono Cooled CameraToupTek · mono · cooled
- Delivery
- Tracked UK delivery. Costs are shown at checkout. Delivery
- Warranty
- Manufacturer warranty, handled by us in the UK.
- Returns
- 14 days to return unused items. Returns policy
Overview
The ToupTek ATR432C is a cooled colour astronomy camera with Sony’s IMX432: 1.8 megapixels of very large 9 µm pixels, a 1.1″ format and a global shutter.
Big pixels match long focal lengths. On a 2000 mm SCT it samples at about 0.93″ per pixel without a reducer. The global shutter reads the whole frame at once, at up to 109 frames per second. There’s no rolling-shutter distortion on the Sun, the Moon or fast-moving targets. Full well is 100 ke⁻. Read noise is high at low gain, so use high gain mode, where it falls to 2.4 e⁻.
Choose the window when you order. The IR-cut version is for normal colour imaging. Clear AR-coated glass lets infrared through, for use with your own filters in front of the camera, such as a dual-band or UV/IR-cut filter.
Cooling, dew and power
Two-stage cooling takes the sensor up to 42 °C below the air temperature. It holds the set point to within 0.1 °C, so dark frames can be reused from night to night. A heater on the front window has four power settings and can be switched off in software. Cooling needs 12 V; the 12 V 3 A power supply is in the box.
Back focus and connections
Back focus is 17.5 mm from the M42 thread. Adapter rings and extension tubes are included to build out to the spacing your flattener or reducer needs, usually 55 mm. A 512 MB buffer holds each frame while it transfers, so a slow USB link doesn’t drop frames.
Specifications
| Sensor | Sony IMX432, colour |
|---|---|
| Sensor format | 1.1″ |
| Sensor size | 14.4 × 9.9 mm |
| Diagonal | 17.5 mm |
| Resolution | 1600 × 1100 px |
| Megapixels | 1.8 MP |
| Pixel size | 9 µm |
| Shutter | Global |
| ADC | 12 bit |
| Full well | 100 ke⁻ |
| Read noise | 20.2–2.4 e⁻ |
| Peak QE | >79% |
| Cooling | Two-stage TEC, 35–45 °C below ambient |
| Max frame rate | 109 fps (12-bit) |
| Image buffer | 512 MB |
| Back focus | 17.5 mm |
| Connection | USB 3.0 |
| Adapters | M42×0.75, M48×0.75 |
| Weight | 552 g |
| Body diameter | 80 mm |
Specifications from the manufacturer. Check with us if a figure matters for your setup.
In the box
- ATR camera
- Power supply, 12 V 3 A, and power cable
- USB 3.0 cable, 1.5 m
- Adapter rings and extension tubes
- Front cap
