Player One Poseidon-C Pro Colour Cooled Camera
Cooled colour camera with the Sony IMX571 APS-C sensor. 26 MP, 3.76 µm pixels, 16-bit.
£1,630.00
No VAT added. The price you see is the price you pay.
Usually in stock
If it isn’t on the shelf when you order, we’ll email you within one working day with a confirmed delivery date, usually within 10 days.
Same IMX571 sensor, other versionsSee all 6
- Player One Poseidon-M Pro Mono Cooled CameraPlayer One · mono · cooled
- ToupTek ATR2600C Colour Cooled CameraToupTek · colour · cooled
- ToupTek ATR2600M Mono Cooled CameraToupTek · mono · cooled
- ToupTek SkyEye26AC Plus Colour Cooled CameraToupTek · colour · cooled
- Delivery
- Tracked UK delivery. Costs are shown at checkout. Delivery
- Warranty
- 2-year manufacturer warranty, handled by us in the UK.
- Returns
- 14 days to return unused items. Returns policy
Overview
The Player One Poseidon-C Pro is a cooled colour astronomy camera built around Sony’s APS-C IMX571 sensor. It is a deep-sky camera for refractors and astrographs.
The 3.76 µm pixels suit short to medium focal lengths. On a 600 mm refractor it samples at 1.29″ per pixel over a field of about 2.2° × 1.5°. The 28.3 mm diagonal needs a flattener or reducer that corrects that much field; 36 mm or 2″ filters cover it.
At low gain each pixel holds 71,700 electrons, over 1.4 times the standard IMX571, and the output is 16-bit. In high-gain mode read noise falls to about 1.4 e⁻ for short exposures and dual-band filters. Dark frames show no amp glow.
Two-stage cooling holds the sensor about 40 °C below the air temperature, at a set point you choose. A heater keeps dew off the window. Tilt is adjusted from the back with a four-point plate.
Back focus is 17.5 mm, or 12.5 mm with the tilt plate removed. A 512 MB buffer stops dropped frames on slower laptops.
The camera weighs 650 g. The cooler runs from 12 V, and the power supply is not included: Player One recommends one rated at 5 A or more.
Specifications
| Sensor | Sony IMX571, colour |
|---|---|
| Sensor format | APS-C |
| Sensor size | 23.5 × 15.7 mm |
| Diagonal | 28.3 mm |
| Resolution | 6252 × 4176 px |
| Megapixels | 26 MP |
| Pixel size | 3.76 µm |
| Shutter | Rolling |
| ADC | 16 bit |
| Full well | 71.7 ke⁻ |
| Read noise | 3.9–1.0 e⁻ |
| Peak QE | 80% |
| Cooling | Two-stage TEC, 40 °C ± 2 °C below ambient |
| Max frame rate | 10 fps (10-bit) |
| Image buffer | 512 MB |
| Back focus | 17.5 mm (12.5 without the tilt plate) |
| Connection | USB 3.0 (Type-C) |
| Adapters | M48×0.75, 2″, 1.25″ |
| Weight | 650 g |
| Body diameter | 90 mm |
Specifications from Player One. Check with us if a figure matters for your setup.
In the box
- Camera with metal cover
- M48 extenders, 17.5 mm and 20 mm
- M48 to M42 adapter
- T-mount and 1.25″ cover
- Air blower
- USB 3.2 cable, Type-C to Type-A, 2 m
- USB 2.0 cables, Type-C to Type-C and Type-C to Type-B, 0.5 m
- M2 hex key and M2.5 screws
- Cable tie
- Camera bag
Not included
- Power supply: 12 V, 5 A or more recommended
